STEERING FOR POLARIS RANGER 1000 DIESEL EU 2015

FRONT SUSPENSION CONTROL ARMS

(1) 5412929

BOOT-SEAL ROD END 10MM

(2) 7061138

ROD-END 10MM 1/2-20LH 42 DEG

(3) 7547028

NUT JAM LH(10)

(4) *******

TIE ROD INNER

(5) 7080978

CLAMP-BOOT SMALL

(6) 5412013

BOOT-PASSENGER SIDE RACK

(7) 7080979

CLAMP-BOOT LARGE

(8) 7518935

BOLT-M8X1.25X95 HX BOLT

(9) 7518644

SCR-M10X1.50X35 HX/FL

(10) 7044098

ASM-SHOCK OIL LOCKING MACH

(11) 7519980

BOLT-SHOULDER M8-15 M6X1.0-BLK

(11) 7519980

BOLT-SHOULDER M8-15 M6X1.0-BLK

(12) 7518665

BOLT-M10X1.25X130 HXFLG-OLIVED

(13) 1824294-458

ASM-TILT STEER RVTD M10 EU BLK

(14) 1823623

WHEEL-STEERING 14

(15) 7547188

NUT-M16X2-6G

(16) 5436536

CAP-STEERING WHEEL

(17) 7518702

BOLT-M8X1.25X20 HXHDFLG

(17) 7518702

BOLT-M8X1.25X20 HXHDFLG

(17) 7518702

BOLT-M8X1.25X20 HXHDFLG

(18) 1823902

ASM-GEAR BOX STEERING

(19) 7546703

NUT NYLOK(10)

(19) 7546703

NUT NYLOK(10)

(20) 1823844

SHAFT-STEERING UPPER/LOWER

(21) 7547385

NUT-NY INS M10X1.5 HEX ZINC YW

(22) 7547332

NUT-M8X1.25 FLG NYLOC-OLIVE D

(23) 5412012

BOOT-DRIVER SIDE RACK

(24) 7517909

BOLT-M10X1.25X65 HX WASH HD

(25) 7661203

PIN COTTER(10)

(26) 7547333

NUT-M10X1.25 FLG NYLOC-OLIVE D

(26) 7547333

NUT-M10X1.25 FLG NYLOC-OLIVE D

(27) 7556675

BUSHING-STEERING

(28) 5632295-458

COLLAR-STEERING LOCK MATTE BLK

(29) 7082045

LOCK-STEERING 1000COMBINATIONS

(30) 7518457

SCR-M5X.8X10 TX BTN PIN-IN-HD

(31) 4015149

SWITCH-BLOCK TURN LIGHTS HORN

	Part number	Description	Qty
# 1	5411920	BOOT-SEAL ROD END 10MM	Contact	0,00 €(0,00 £)
# 2	7061054	ROD-END 10MM 1/2-20LH 42 DEG	Contact	0,00 €(0,00 £)
# 3	7547028	NUT JAM LH(10)	Contact	0,00 €(0,00 £)
# 4	*******	TIE ROD INNER	Contact	0,00 €(0,00 £)
# 5	7080978	CLAMP-BOOT SMALL	Contact	0,00 €(0,00 £)
# 6	5412013	BOOT-PASSENGER SIDE RACK	Contact	0,00 €(0,00 £)
# 7	7080979	CLAMP-BOOT LARGE	Contact	0,00 €(0,00 £)
# 8	7518935	BOLT-M8X1.25X95 HX BOLT	Contact	0,00 €(0,00 £)
# 9	7518644	SCR-M10X1.50X35 HX/FL	Contact	0,00 €(0,00 £)
# 10	7044098	ASM-SHOCK OIL LOCKING MACH	Contact	0,00 €(0,00 £)
# 11	7519980	BOLT-SHOULDER M8-15 M6X1.0-BLK	Contact	0,00 €(0,00 £)
# 12	7518665	BOLT-M10X1.25X130 HXFLG-OLIVED	Contact	0,00 €(0,00 £)
# 13	1824294-458	ASM-TILT STEER RVTD M10 EU BLK	Contact	0,00 €(0,00 £)
# 14	1823623	WHEEL-STEERING 14	Contact	0,00 €(0,00 £)
# 15	7547188	NUT-M16X2-6G	Contact	0,00 €(0,00 £)
# 16	5436536	CAP-STEERING WHEEL	Contact	0,00 €(0,00 £)
# 17	7518702	BOLT-M8X1.25X20 HXHDFLG	Contact	0,00 €(0,00 £)
# 18	1823902	ASM-GEAR BOX STEERING	Contact	0,00 €(0,00 £)
# 19	7546703	NUT NYLOK(10)	Contact	0,00 €(0,00 £)
# 20	1823844	SHAFT-STEERING UPPER/LOWER	Contact	0,00 €(0,00 £)
# 21	7547385	NUT-NY INS M10X1.5 HEX ZINC YW	Contact	0,00 €(0,00 £)
# 22	7547332	NUT-M8X1.25 FLG NYLOC-OLIVE D	Contact	0,00 €(0,00 £)
# 23	5412012	BOOT-DRIVER SIDE RACK	Contact	0,00 €(0,00 £)
# 24	7517909	BOLT-M10X1.25X65 HX WASH HD	Contact	0,00 €(0,00 £)
# 25	7661203	PIN COTTER(10)	Contact	0,00 €(0,00 £)
# 26	7547333	NUT-M10X1.25 FLG NYLOC-OLIVE D	Contact	0,00 €(0,00 £)
# 27	7556675	BUSHING-STEERING	Contact	0,00 €(0,00 £)
# 28	5632295-458	COLLAR-STEERING LOCK MATTE BLK	Contact	0,00 €(0,00 £)
# 29	7082045	LOCK-STEERING 1000COMBINATIONS	Contact	0,00 €(0,00 £)
# 30	7518457	SCR-M5X.8X10 TX BTN PIN-IN-HD	Contact	0,00 €(0,00 £)
# 31	4015149	SWITCH-BLOCK TURN LIGHTS HORN	Contact	0,00 €(0,00 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Polaris. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the STEERING - R15RTAD1FA (700115) of your Polaris RANGER 1000 DIESEL EU of 2015. Let us know if you have any questions.
