ACCELERATOR CONTROL

ENGINE, AIR INTAKE FOR POLARIS RANGER 1000 DIESEL EU 2015

ENGINE, ALTERNATOR

(1) 7547332

NUT-M8X1.25 FLG NYLOC-OLIVE D

(2) 5137652

BSHG-FLG 21X9.5X10.5

(3) 5414160

GROMMET-BASE TOP

(4) 1240625

ASM-AIRBOX LID

(5) 1204787

ASM-BELLHOUSING

(6) 7081707

CLIP-AIRBOX

(7) 5414330

HOSE-INTAKE ENG

(7) 5415594

HOSE-INTAKE ENG

(8) 5414472

PLUG-DRAIN

(9) 5414543

HOSE-INTAKE AIR BOX

(10) 7080446

CLAMP-HOSE 2.75-SS

(10) 7080446

CLAMP-HOSE 2.75-SS

(10) 7080446

CLAMP-HOSE 2.75-SS

(11) 7081706

FILTER-AIRBOX MAIN

(12) 1240883

WELD-INTAKE PLENUM

(13) 5138987

SHAFT-COMPRESSION LMTR 34.4MM

(14) 5255273

BRACKET AIRBOX MOUNT

(15) 5414542

HOSE-INTAKE BOOT

(16) 5414719

BUSHING-MOUNT

(17) 5415075

HOSE-INTAKE ENG DSL

(18) 5439201-070

INTAKE-FENDER REAR BLK

(19) 5439947

DUCT-INTAKE AIR

(20) 5416499

CAP-RUBBER .75 ID X 1.00

(21) 7080439

CLAMP HOSE

(21) 7080439

CLAMP HOSE

(22) 7080511

CLAMP NARROW BAND

(23) 7080614

CLAMP HOSE

(24) 7080707

CLAMP BAND NARROW (10)

(25) 7518238

SCR-10X5/8-HI/LO PN-T25 TRX-M

(26) 7518529

SCR-M6X1.0X20 HXHD FLG TDFM BL

(27) 7519298

SCR-HXFL-M8X1.25X60 8.8 ZOD

(28) 7519342

SCR-TFHFL-M6X1.0X25 ZOD

	Part number	Description	Qty
# 1	7547332	NUT-M8X1.25 FLG NYLOC-OLIVE D	Contact	0,00 €(0,00 £)
# 2	5137652	BSHG-FLG 21X9.5X10.5	Contact	0,00 €(0,00 £)
# 3	5414160	GROMMET-BASE TOP	Contact	0,00 €(0,00 £)
# 4	5439197	ASM-AIRBOX LID	Contact	0,00 €(0,00 £)
# 5	1204787	ASM-BELLHOUSING	Contact	0,00 €(0,00 £)
# 6	7081707	CLIP-AIRBOX	Contact	0,00 €(0,00 £)
# 7	5414330	HOSE-INTAKE ENG	Contact	0,00 €(0,00 £)
# 7	5415594	HOSE-INTAKE ENG	Contact	0,00 €(0,00 £)
# 8	5414472	PLUG-DRAIN	Contact	0,00 €(0,00 £)
# 9	5414543	HOSE-INTAKE AIR BOX	Contact	0,00 €(0,00 £)
# 10	7080446	CLAMP-HOSE 2.75-SS	Contact	0,00 €(0,00 £)
# 11	7081706	FILTER-AIRBOX MAIN	Contact	0,00 €(0,00 £)
# 12	1240883	WELD-INTAKE PLENUM	Contact	0,00 €(0,00 £)
# 13	5138987	SHAFT-COMPRESSION LMTR 34.4MM	Contact	0,00 €(0,00 £)
# 14	5255273	BRACKET AIRBOX MOUNT	Contact	0,00 €(0,00 £)
# 15	5414542	HOSE-INTAKE BOOT	Contact	0,00 €(0,00 £)
# 16	5414719	BUSHING-MOUNT	Contact	0,00 €(0,00 £)
# 17	5415075	HOSE-INTAKE ENG DSL	Contact	0,00 €(0,00 £)
# 18	5439201	INTAKE-FENDER REAR BLK	Contact	0,00 €(0,00 £)
# 19	5439947	DUCT-INTAKE AIR	Contact	0,00 €(0,00 £)
# 20	5451216	CAP-RUBBER .75 ID X 1.00	Contact	0,00 €(0,00 £)
# 21	7080439	CLAMP HOSE	Contact	0,00 €(0,00 £)
# 22	7080511	CLAMP NARROW BAND	Contact	0,00 €(0,00 £)
# 23	7080614	CLAMP HOSE	Contact	0,00 €(0,00 £)
# 24	7080707	CLAMP BAND NARROW (10)	Contact	0,00 €(0,00 £)
# 25	7518238	SCR-10X5/8-HI/LO PN-T25 TRX-M	Contact	0,00 €(0,00 £)
# 26	7518529	SCR-M6X1.0X20 HXHD FLG TDFM BL	Contact	0,00 €(0,00 £)
# 27	7519298	SCR-HXFL-M8X1.25X60 8.8 ZOD	Contact	0,00 €(0,00 £)
# 28	7519342	SCR-TFHFL-M6X1.0X25 ZOD	Contact	0,00 €(0,00 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Polaris. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the ENGINE, AIR INTAKE - R15RTAD1FA (49RGRAIRINTAKE15DSL) of your Polaris RANGER 1000 DIESEL EU of 2015. Let us know if you have any questions.
