SWING ARM / REAR / GEARCASE MOUNTING FOR POLARIS 500 MAGNUM 4X4 HDS 2003

TOOL KIT

Item numbers
SWING ARM/REAR/GEARCASE MOUNTING - A03CD50FB (4975277527C12) Polaris ATV 500 2003 500 MAGNUM 4X4 HDS 500 MAGNUM 4X4 HDS - A03CD50FB
1
2
3
4
5
5
5
5
5
5
5
5
5
6
6
6
7
7
8
9
10
11
11
12
12
13
13
14
15
15
16
17
18
19
19
20
21
22
23
24
25
25
25
25
25
25
25
25
25
26
27
28
29
30
31
32
33
34
1
O-RING-0.739X0.879X0.070

5412022  

Not available
2
HUB-WHEEL AWD MACH

5133360  

Not available
3
STUD 3/8-24X1.12 PRS FIT-Z (10

7515513  

Not available
4
DISC-BRAKE REAR 8.125X.188

5244882  

Not available
5
ASM. BRAKE CALIPER [SEE REAR BRAKE PG. C2 FOR DETAILS]

 

Not available
6
BOLT

7517604  

Not available
7
WASHER(10)

7555721  

Not available
8
NUT-1/2-20 NYLOK Y

7547065  

Not available
9
NUT-JAM

5133387  

Not available
10
PIVOT-THREADED LH

5133388  

Not available
11
BEARING-TAPERED ROLLER CONE

3514399  

Not available
12
BEARING-TAPERED ROLLER CUP

3514398  

Not available
13
FOAM

5812447  

Not available
14
ASM-SWINGARM 3/4 PIVOT

1541820  

Not available
15
O-RING-1.046X1.324X.139

5412202  

Not available
16
ASM-PROP SHAFT REAR

1380202  

Not available
17
PIN SPRING(10)

7661913  

Not available
18
PIVOT-THREADED SWINGARM RH

5133389  

Not available
19
WASHER SPLIT LOCK

7553201  

Not available
20
BOLT-1/2-13X1 1/4 HXHD GR5-Z

7517585  

Not available
21
AXLE-REAR

5133626  

Not available
22
SCREW

7517612  

Not available
23
O-RING

5411531  

Not available
24
ASM. GEARCASE REAR [SEE REAR HOUSING PG. C8 FOR DETAILS]

 

Not available
25
ASM. SKID PLATE REAR

1012881  

Not available
25
PAD-RUBBER

5811716  

Not available
25
PLATE-SKID BLK

5242851067  

Not available
26
COLLAR-AXLE LOCK

5132698  

Not available
27
O-RING

5411707  

Not available
28
DECAL-HITCH 1000 LBS.

7170910  

Not available
29
CLAMP-BRAKE LINE REAR

5245050  

Not available
30
SCREW

7512017  

Not available
31
AXLE TUBE LH BLK VL

1013264067  

Not available
32
BEARING-WHEEL 35X64X37MM

3514342  

Not available
33
RING RET. 2.500 INTERNAL

7710507  

Not available
34
BOLT

7512325  

Not available
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Polaris. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Polaris, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
