REAR BRAKE / FOOT PEDAL ASSEMBLY 4X4 350L S938139 (4924342434028A)

REAR BRAKE / FOOT PEDAL ASSEMBLY 4X4 350L W938139 (4924052405028A) FOR POLARIS EURO 350L 4X4 1993

BODYWORK

(1) 1930691

KNOB BRAKE ADJUSTOR

(2) 7542129

NUT

(3) 7555828

WASHER SPRING

(4) 5222664

ARM BRAKE CALIPER

(5) 3610026

SEAL BRAKE

(6) 2200391

KIT AUX BRAKE RAMP

(7) 2200391

KIT AUX BRAKE RAMP

(8) 5830009

GASKET BRAKE

(9) 5020523

PIN BRAKE ADJUSTER

(10) 7041219

SPRING BRAKE COMP.

(11) 5411432

O RING (10)

(12) 7080352

SCREW BLEEDER (10)

(13) 1910073

ASM-BRAKE CALIPER REAR

(13) 5130714

CALIPER REAR BRAKE

(14) 7661820

PIN DOWEL

(15) 7512020

SCREW SEMS

(16) 5211143

PLATE PIN

(17) 2200464

KIT REAR.BRAKEPAD MED.DUTY

(18) 5410518

RING SQUARE (.120)

(19) 5410519

RING SQUARE (.066 SQ.)

(20) 5020521

PISTON BRAKE

(21) 4110089

SWITCH STOPLIGHT

(22) 5222232

SPRING ANTI-RATTLE

(23) 7512292

BOLT SOC. HD.(10)

(24) 7555827

WASHER

(24) 7555827

WASHER

(24) 7555827

WASHER

(25) 5224437

ROD BRAKE LINKAGE

(26) 7661416

PIN SPIRAL

(27) 5130715-067

PEDAL FOOT

(28) 7042029

SPRING(10)

(29) 1910045-067

PEDAL BRAKE

(30) 7661103

PIN COTTER

(31) 7558702

WASHER THRUST

(31) 7558702

WASHER THRUST

(32) 5431107

BUSHING PEDAL PIVOT

(33) 7661401

PIN COTTER(10)

	Part number	Description	Qty
# 1	1930691	KNOB BRAKE ADJUSTOR	Contact	0,00 €(0,00 £)
# 2	7542129	NUT	Contact	0,00 €(0,00 £)
# 3	7555828	WASHER SPRING	Contact	0,00 €(0,00 £)
# 4	5222664	ARM BRAKE CALIPER	Contact	0,00 €(0,00 £)
# 5	3610026	SEAL BRAKE	Contact	0,00 €(0,00 £)
# 6	5630395	KIT AUX BRAKE RAMP	Contact	0,00 €(0,00 £)
# 7	5630394	KIT AUX BRAKE RAMP	Contact	0,00 €(0,00 £)
# 8	5830009	GASKET BRAKE	Contact	0,00 €(0,00 £)
# 9	5020523	PIN BRAKE ADJUSTER	Contact	0,00 €(0,00 £)
# 10	7041219	SPRING BRAKE COMP.	Contact	0,00 €(0,00 £)
# 11	5410542	O RING (10)	Contact	0,00 €(0,00 £)
# 12	7080352	SCREW BLEEDER (10)	Contact	0,00 €(0,00 £)
# 13	1910073	ASM-BRAKE CALIPER REAR	Contact	0,00 €(0,00 £)
# 13	5130714	CALIPER REAR BRAKE	Contact	0,00 €(0,00 £)
# 14	7661820	PIN DOWEL	Contact	0,00 €(0,00 £)
# 15	7512020	SCREW SEMS	Contact	0,00 €(0,00 £)
# 16	5211143	PLATE PIN	Contact	0,00 €(0,00 £)
# 17	2200464	KIT REAR.BRAKEPAD MED.DUTY	Contact	0,00 €(0,00 £)
# 18	5410518	RING SQUARE (.120)	Contact	0,00 €(0,00 £)
# 19	5410519	RING SQUARE (.066 SQ.)	Contact	0,00 €(0,00 £)
# 20	5020521	PISTON BRAKE	Contact	0,00 €(0,00 £)
# 21	4110089	SWITCH STOPLIGHT	Contact	0,00 €(0,00 £)
# 22	5222232	SPRING ANTI-RATTLE	Contact	0,00 €(0,00 £)
# 23	7512292	BOLT SOC. HD.(10)	Contact	0,00 €(0,00 £)
# 24	7555827	WASHER	Contact	0,00 €(0,00 £)
# 25	5224437	ROD BRAKE LINKAGE	Contact	0,00 €(0,00 £)
# 26	7661416	PIN SPIRAL	Contact	0,00 €(0,00 £)
# 27	5130715-067	PEDAL FOOT	Contact	0,00 €(0,00 £)
# 28	7042029	SPRING(10)	Contact	0,00 €(0,00 £)
# 29	1910045-067	PEDAL BRAKE	Contact	0,00 €(0,00 £)
# 30	7661103	PIN COTTER	Contact	0,00 €(0,00 £)
# 31	7558702	WASHER THRUST	Contact	0,00 €(0,00 £)
# 32	5431107	BUSHING PEDAL PIVOT	Contact	0,00 €(0,00 £)
# 33	7661401	PIN COTTER(10)	Contact	0,00 €(0,00 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Polaris. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the REAR BRAKE/FOOT PEDAL ASSEMBLY 4X4 350L W938139 (4924052405028A) of your Polaris Euro 350L 4x4 - S938139 of 1993. Let us know if you have any questions.
