DRIVE TRAIN, CLUTCH COVER AND DUCTING

DRIVE TRAIN, MAIN GEARCASE FOR POLARIS ACE 150 MD 2017

DRIVE TRAIN, PRIMARY CLUTCH

(1) 3050284

GEAR BOX COVER

(2) 3050349

GEAR BOX GASKET

(3) 3050286

ASM TRANSMISSION SHAFT

(4) 3050287

GEARSHIFT DRUM

(5) 3050288

FORK SHAFT

(6) 3050289

F0RK

(7) 3050290

ASM GEARSHIFT SHAFT

(8) 3050291

DRIVE SHAFT

(9) 3050292

CIRCLIP 20

(10) 3050293

O-RING 10X2.3

(11) 3050294

WASHER-15X19X1 STEEL

(12) 3050295

ASM-REVERSE GEAR SHAFT

(13) 3050296

ASM-OUTPUT SHAFT

(14) 3050342

BALL BEARING 6302

(15) 3050323

BALL BEARING 6204

(16) 3050297

NEEDLE BEARING RNA4905

(17) 3050298

DOWEL PIN 10X14

(18) 3050299

OIL SEAL 30X40X6

(19) 3050300

BALL BEARING 6205-2RS

(20) 3050301

WASHER-25X34X1

(21) 3050302

CIRCLIP 25

(22) 3050303

CIRCLIP 52

(23) 3050304

BOLT- M6X40

(24) 3050305

CABLE SHIFT INDICATOR

(25) 3050306

BOLT M6X12

(26) 3050307

SHIFT INDICATOR CONTACT

(27) 3050308

CABLE CLAMP

(28) 3050309

OIL SEAL 14X22X5

(29) 3050310

OIL SEAL 14X28X7

(30) 3050030

WASHER 12

(31) 3050031

BOLT-M12X1.5

	Part number	Description	Qty
# 1	3050284	GEAR BOX COVER	Contact	0,00 €(0,00 £)
# 2	3050285	GEAR BOX GASKET	Contact	0,00 €(0,00 £)
# 3	3050286	ASM TRANSMISSION SHAFT	Contact	0,00 €(0,00 £)
# 4	3050287	GEARSHIFT DRUM	Contact	0,00 €(0,00 £)
# 5	3050288	FORK SHAFT	Contact	0,00 €(0,00 £)
# 6	3050289	F0RK	Contact	0,00 €(0,00 £)
# 7	3050290	ASM GEARSHIFT SHAFT	Contact	0,00 €(0,00 £)
# 8	3050291	DRIVE SHAFT	Contact	0,00 €(0,00 £)
# 9	3050292	CIRCLIP 20	Contact	0,00 €(0,00 £)
# 10	3050293	O-RING 10X2.3	Contact	0,00 €(0,00 £)
# 11	3050294	WASHER-15X19X1 STEEL	Contact	0,00 €(0,00 £)
# 12	3050295	ASM-REVERSE GEAR SHAFT	Contact	0,00 €(0,00 £)
# 13	3050296	ASM-OUTPUT SHAFT	Contact	0,00 €(0,00 £)
# 14	3050342	BALL BEARING 6302	Contact	0,00 €(0,00 £)
# 15	3050323	BALL BEARING 6204	Contact	0,00 €(0,00 £)
# 16	3050297	NEEDLE BEARING RNA4905	Contact	0,00 €(0,00 £)
# 17	3050298	DOWEL PIN 10X14	Contact	0,00 €(0,00 £)
# 18	3050299	OIL SEAL 30X40X6	Contact	0,00 €(0,00 £)
# 19	3050300	BALL BEARING 6205-2RS	Contact	0,00 €(0,00 £)
# 20	3050301	WASHER-25X34X1	Contact	0,00 €(0,00 £)
# 21	3050302	CIRCLIP 25	Contact	0,00 €(0,00 £)
# 22	3050303	CIRCLIP 52	Contact	0,00 €(0,00 £)
# 23	3050304	BOLT- M6X40	Contact	0,00 €(0,00 £)
# 24	3050305	CABLE SHIFT INDICATOR	Contact	0,00 €(0,00 £)
# 25	3050306	BOLT M6X12	Contact	0,00 €(0,00 £)
# 26	3050307	SHIFT INDICATOR CONTACT	Contact	0,00 €(0,00 £)
# 27	3050308	CABLE CLAMP	Contact	0,00 €(0,00 £)
# 28	3050309	OIL SEAL 14X22X5	Contact	0,00 €(0,00 £)
# 29	3050310	OIL SEAL 14X28X7	Contact	0,00 €(0,00 £)
# 30	3050030	WASHER 12	Contact	0,00 €(0,00 £)
# 31	3050031	BOLT-M12X1.5	Contact	0,00 €(0,00 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Polaris. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Polaris, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
